V46 series_Gauge Root Valves

Model name V46 series_Gauge Root Valves
Manufacturer DK Tech Corporation
Purpose Gauge Root Valves
Enquiry telephone 051-324-8045
Product description
  1. Up to 6000psig (413bar)
  2. Up to 450℉ (232℃)
  3. S316,Carbon Steel
  4. Pipe thread 1/2 – 3/4 inch
  5. Standard gauge valve, longer body gauge root valve and extended 4″ long body for pipe insulation are standard
  6. Grafoil packing for high temperature available
  7. Non-rotating globe stem tip
  8. Stem seal below actuating threads
